Cisco Catalyst 2960XR-24TD-I - switch - 24 ports - managed - desktop, rack-mountable

Part: WS-C2960XR-24TD-I
Availability: Out of Stock
Price: $1,714.00

Product Information

Cisco Catalyst 2960XR-24TD-I - Switch - L3 - managed - 24 x 10/100/1000 + 2 x SFP+ - desktop, rack-mountable

Cisco Catalyst 2960-X series switch is a fixed-configuration, stackable Gigabit Ethernet switch that provides enterprise-class access for campus and branch applications. Designed for operational simplicity to lower total cost of ownership, it enables scalable, secure and energy-efficient business operations with intelligent services.

Device Type: Switch - 24 ports - L3 - managed - stackable
Enclosure Type: Desktop, rack-mountable 1U
Interfaces: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 2 x SFP+
Performance: Switching capacity : 216 Gbps
Forwarding performance: 95.2 Mpps
Forwarding performance: 95.2 Mpps
Capacity: Virtual interfaces (VLANs) : 1023
Jumbo Frame Support: 9216
Routing Protocol: OSPF, RIP-1, RIP-2, HSRP, VRRP, PIM-SM, PIM-DM, PIM-SSM, policy-based routing (PBR), RIPng
Remote Management Protocol: SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, CLI
Features: Layer 2 switching, auto-negotiation, ARP support, Cisco Fast EtherChannel, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, MLD snooping, Dynamic ARP Inspection (DAI), Uni-Directional Link Detection (UDLD), Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), layer 3 load balancing, Per-VLAN Rapid Spanning Tree (PVRST), Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Strict Priority Queuing (SPQ), Class of Service (CoS)
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3az
Power: AC 120/230 V ( 50/60 Hz )
Power Redundancy: Yes
Dimensions: (WxDxH)17.5 in x 16.1 in x 1.8 in
Weight: 13 lbs
